Features:
These are V-bank filters that are employed as high-efficiency air filtration solutions in HVAC and industrial applications. They ensure proper filtration performance while offering a higher dust-holding capacity with minimal pressure drop. They are made out of synthetic media in order to maximize the capture of airborne contaminants such as dust, pollen, mold spores, and bacteria. The V-bank filter improves air quality by safeguarding the equipment and providing cleanliness with healthy surroundings. Its applications are quite significant in hospitals, clean rooms, commercial facilities, and industrial locations with effective air filtration and protection.

• Optional Thickness :292 / 400mm
• Separator :Hot melt bead
• Gasket :EVA / EPDM
• Sealant :Pu two-component polyurethane glue
• Frame :Plastic frame
• Media :Micron glass fiber
• Efficiency :F6 / F7 / F8 / F9 / H10 / H11 / H12
• Max Temperature :70℃
• Max Humidity :100%

Panel air filters are part of an HVAC system, designed to remove impurities from airflow. These filters maintain good indoor air quality and protect equipment from damage caused by debris buildup. Commonly less than 6 inches in depth, these filters maintain low- to moderatelevels of filtration and are often used as pre-filters. They capture larger particles, which helps extend the life of more expensive final filters further down the stream. Panel air filters are used in office buildings, universities, and colleges as well as other work environments with surface finishing technologies.

• Optional Thickness :10 / 17 / 21 / 25 mm
• Frame :Aluminum / GI
• Media :Synthetic fiber
• Max Temperature :50℃
• Max Humidity :100%
• Face guard :Square mesh / Grid mesh / Sprayed metal net
